1-36
Seat, seatbelt and SRS airbags
instructions by the child restraint system
manufacturer.
! Outback
! To hook the top tether
CAUTION
Since a top tether can provide additional
stability by offering another connection
between a child restraint system and the
vehicle, we recommend that you use a top
tether whenever one is required or available.
Always remove the head restraint
when mounting a child restraint
system with a top tether. Failure to
do so may prevent the top tether
from being fastened tightly.
! Tether anchorage location
! Legacy
! Legacy
Three tether anchorages, i.e., ones for the
right, center and left positions, are already
installed on the rear edge of the roof.
Open the cover flap to use each anchorage.
Three tether anchorages are installed on
the rear shelf behind the rear seat head
restraint. Open the cover flap to use each
anchorage.
1. Fold down the rear seatback for the
window side seating position. Refer to
“Folding down the rear seatback” F1-8.
2. Remove the head restraint at the
seating position where the child restraint
system has been installed with the seatbelt or lower anchorages; lift up the head
