Instruments and controls
3. To change the current setting, press
the trip knob for at least 2 seconds.
: Activated
: Deactivated
NOTE
. The initial setting for your vehicle of
the gear position indicator and shift-up
indicator has been set for activation
“
” at the time of shipment from the
factory.
. It is not possible to change the
setting of the gear position indicator/
shift-up indicator when the ignition
switch is in the “ON” position. Change
the setting when the ignition switch is
in the “LOCK” or “Acc” position.
& Turn signal indicator
lights
These lights show the operation of the turn
signal or lane change signal.
If the indicator lights do not blink or blink
rapidly, the turn signal bulb may be burned
out. Replace the bulb as soon as possible.
Refer to “Replacing bulbs” F11-50.
3-23
& High beam indicator
& Cruise control set in-
This light shows that the headlights are in
the high beam mode.
This indicator light also illuminates when
the headlight flasher is operated.
The cruise control set indicator light
illuminates when the ignition switch is
turned to the “ON” position and turns off
after approximately 3 seconds.
This light illuminates when vehicle speed
has been set.
light
& Cruise control indicator light
The cruise control indicator light illuminates when the ignition switch is turned to
the “ON” position and turns off after
approximately 3 seconds.
This light illuminates when the “CRUISE”
main switch is pressed.
NOTE
. If you move the cruise control lever
or press the main switch button while
turning the ignition switch “ON”, the
cruise control function is deactivated
and the “CRUISE” indicator light
flashes. To reactivate the cruise control
function, turn the ignition switch back
to the “Acc” or “LOCK” position, and
then turn it again to the “ON” position.
. If this indicator light and the CHECK
ENGINE warning light/malfunction indicator lamp flash simultaneously during driving, have the vehicle checked
by your nearest SUBARU dealer.
dicator light
& Headlight indicator
light
This indicator light illuminates under the
following conditions.
. when the light switch is turned to the
“
” or “ ” position
. when the light switch is in the “AUTO”
position and the headlights illuminate
automatically
& Front fog light indicator
light (if equipped)
This indicator light illuminates while the
front fog lights are illuminated.
