78
SRS Airbag ( Supplemental Restraint System Airbag )
1 . Raise the head restraint at the seating position where the child restraint system is to be installed with the seatbelt or lower anchorages .
2 . Adjust the seatback to the upright position .
3 . Pass the top tether between the head restraint and seatback .
4 . Attach the top tether hook to the appropriate upper anchorage .
5 . Tighten the top tether securely .
SUBARU recommends that you check with a certified Child Passenger Safety Technician to ensure the proper installation of your child restraint system . For more information , and to locate the closest inspection location in the U . S ., refer to the National Highway Traffic Safety Administration ( NHTSA ) website . In Canada , check with Transport Canada .
1-9 . SRS Airbag ( Supplemental Restraint System Airbag )
s01ah
Supplemental Restraint System ( SRS ) name is used because the airbag system supplements the vehicle ’ s seatbelts .
This vehicle is equipped with a supplemental restraint system which consists of eight airbags .
The configurations are as follows .
. Driver ’ s and front passenger ’ s frontal airbags
. Driver ’ s and front passenger ’ s side airbags
. Front passenger ’ s seat cushion airbags
. Curtain airbags ( for driver , front passenger , and window-side rear passengers )
. Knee airbag for driver
These SRS airbags are designed only to be a supplement to the primary protection provided by the seatbelt .
The system also controls front seatbelt pretensioners . For operation instructions and precautions concerning the seatbelt pretensioner , refer to “ Seatbelt Pretensioners ” FP55 .
