526
Air Cleaner Element
11-8 . Air Cleaner Element
WARNING s11ag
Do not operate the engine with the air cleaner element removed . The air cleaner element not only filters intake air but also stops flames if the engine backfires . If the air cleaner element is not installed when the engine backfires , you could be burned .
& Replacing the Air Cleaner Element s11ag01
Replace the air cleaner element according to the maintenance schedule in the “ Warranty and Maintenance Booklet ”. Under extremely dusty conditions , replace it more frequently . It is recommended that you always use genuine SUBARU parts .
! 2.5 L models s11ag0111
2 . Open the air cleaner case and pull the cover rearward while lifting it up .
CAUTION
When replacing the air cleaner element , use a genuine SUBARU air cleaner element . If it is not used , there is the possibility of causing a negative effect to the engine .
The air cleaner element functions as a filter screen . When the element is perforated or removed , engine wear will be excessive and engine life shortened .
The air cleaner element is a dry type . It is unnecessary to clean or wash the element .
1 ) Clips
1 . Unsnap the two clips holding the air cleaner case ( rear ).
3 . Remove the air cleaner element . CAUTION
If the inside of the air cleaner case is extremely soiled ( for example , by sand ), contact a SUBARU dealer and have the air cleaner case cleaned .
4 . If you find large foreign objects such as leaves inside the air cleaner case , remove the foreign objects .
