Trailer Hitch ( Outback / Subaru Outback Wilderness – If Equipped )
around the drilled hole .
. Be sure your trailer has safety chains and that each chain will hold the trailer ’ s maximum gross weight . Towing trailers without safety chains could create a traffic safety hazard if the trailer separates from the hitch due to coupling damage or hitch ball damage .
. Use only a ball mount that is suitable for the trailer hitch . Use the hitch only as a weight carrying hitch . Do not use with any type of weight distributing hitch .
. The standard bumper beam must be installed after you remove the trailer hitch . Consult a SUBARU dealer for purchase of a standard bumper beam if you do not have the original .
. If a trailer hitch is installed , it is not possible to install the rear towing hook .
When any of the tires are punctured , you can seal the tire temporarily . However , do not tow a trailer when a sealed tire is used . We recommend that you consult the nearest SUBARU dealer for details .
The maximum gross trailer weight and maximum gross tongue weight are indicated in the following table .
2.4 L models
2.5 L models
Maximum gross trailer weight
3,500 lbs ( 1,588 kg )
2,700 lbs ( 1,224 kg )
Maximum gross tongue weight
350 lbs ( 159 kg )
270 lbs ( 122 kg )
When towing a trailer , refer to “ Trailer Towing ( Outback / Subaru Outback Wilderness )” FP467 .
& Connecting a SUBARU Genuine Trailer Hitch s08ak01
1 . Remove the receiver cover from the hitch receiver tube . Then insert the ball mount into the hitch receiver tube .
2 . Insert the hitch pin into the hole located on the hitch receiver tube so that the pin passes through the ball mount .
CAUTION
Do not modify the vehicle exhaust system , brake system , or other systems when installing a hitch or other trailer towing equipment .
