BSD / RCTA 413 |
|||||||||||||||||
|
& BSD / RCTA Warning Indicator s07bm04
! System malfunction s07bm0403
|
This display appears when a malfunction occurs in the system . Contact a SUBARU dealer and have the system inspected .
|
& To Turn On / Off the BSD / RCTA s07bm09 |
BSD / RCTA OFF indicator
To turn the BSD / RCTA system on and off , operate the center information display . Refer to “ Car settings ” FP226 ( 11.6-inch display models ).
When the BSD / RCTA system is turned OFF , the BSD / RCTA OFF indicator on the combination meter display ( color LCD ) will illuminate .
NOTE
. In the following cases , turn off the BSD / RCTA system . The system may not operate properly due to blocked radar waves . – When towing a trailer ( Outback / Subaru Outback Wilderness ) – When a bicycle carrier or other
|
item is fitted to the rear of the vehicle – When using a chassis dynamometer or free roller device , etc . – When running the engine and making the wheels rotate while lifting up the vehicle . If the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the last known status of the system is maintained . For example , if the ignition switch is turned to the “ LOCK ”/“ OFF ” position with the BSD / RCTA deactivated , the BSD / RCTA remains deactivated the next time the ignition switch is turned to the “ ON ” position . |
& Certification for the BSD / RCTA s07bm06
. The U . S . and other FCC compliant countries
FCC ID : OAYSRR3A
CAUTION
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user ’ s authority to operate the equipment .
|
7
Starting and Operating
|
|||||||||||
– CONTINUED – |
