Front View Monitor 399 |
|||||||
7-18 . Front View Monitor ( If Equipped ) |
s07bq
The image from the camera mounted inside the front grille is displayed in the center information display .
WARNING
. Never rely on only the Front View Monitor when driving the vehicle . The image on the monitor screen may be different from the actual situation . If you drive the vehicle by viewing only the monitor image , a collision or an unexpected accident may occur . When driving the vehicle , always check the traffic around the vehicle directly
|
with your eyes and the mirrors .
. Always operate the vehicle as you would without the Front View Monitor .
. Do not use the Front View Monitor in the following situations .
– You are driving on a dirt road or a road covered in snow .
– The camera malfunctions ( e . g . the lens or bracket is broken ).
. If the outside temperature is low , the monitor screen may become dark or the image may become dim . In particular , the image of a moving object may be distorted or disappear from the screen . You must always check the traffic around the vehicle directly with your eyes when driving it .
NOTE
If there is a malfunction on the center information display , refer to “ Malfunctions of the Center Information Display ” FP498 .
|
& How to Access the Front View Monitor s07bq01 |
1 ) Front view monitor switch
To change over to the camera screen , make sure the ignition switch is in the “ ON ” position , then press the front view monitor switch under the following conditions .
. The vehicle speed is below 12 mph ( 20 km / h ).
. The select lever is in except “ R ”.
NOTE
The screen will change over to the rear view image when the select lever is moved to “ R ”. Refer to “ Rear View Camera ” FP402 .
|
7
Starting and Operating
|
||
– CONTINUED – |
