Mirrors 285 |
||||||||
|
! Camera calibration error
s03ap110602
|
When there is a camera calibration error , the warning indicators will appear as shown in the illustration .
When the warning indicators appear , operate the mode lever to select the mirror mode . In such a case , we recommend that you consult your SUBARU dealer for repair .
|
! Maintenance
s03ap1104
|
1 ) Camera
. Make sure to clean the Smart Rearview Mirror and the area around the camera regularly . If these parts are not clean , the screen cannot be seen clearly .
. Wipe off the Smart Rearview Mirror and the area around the camera by using a dry soft cloth . If the foreign matter cannot be removed , first wipe the area off using a wet soft cloth , and then wipe using a dry cloth .
. Do not use alcohol , benzine or thinner for cleaning . Doing so could result in discoloration , deterioration , or malfunction .
. Make sure to clean the rear camera lens regularly . When you clean the rear camera lens , first soak a soft cloth with
|
diluted mild detergent to wipe it off , and wipe using a dry cloth .
. During snowy weather , remove the accumulated snow from around the antenna , because snow interferes with the camera image on the mirror .
. When installing a roof box or a similar accessory , do not block the area in front of the camera lens to avoid interfering with the camera image on the mirror .
. When the Smart Rearview Mirror ’ s visibility is poor because there is dirt or other foreign material adhering to the camera , switch to the original rearview mirror .
! Tips s03ap1105
. Do not use the display mode for a long time while the engine is not running . Doing so could result in the battery discharge .
. Do not install radio antennas around the Smart Rearview Mirror . Radio waves may disturb the Smart Rearview Mirror screen .
. Observe the following instructions . Not doing so could result in malfunction or the main mirror unit falling off . – Do not push the button too strongly or move the lever too forcibly . – Do not turn the main mirror unit more than 90 degrees . – Do not impact the main mirror unit .
|
3
Instruments and Controls
|
|||
– CONTINUED – |
