13-4
Consumer information and Reporting safety defects/Tire information
! Maximum load rating
S13AB010302
The load rating at the maximum
permissible weight load for this tire.
For example, “MAX. LOAD 615 kg
(1,356 LBS) @ 350 kPa (51 PSI)
MAX. PRESS.”
WARNING
Maximum load rating applies
only to the tire, not to the
vehicle. Putting a load rated
tire on any vehicle does not
mean the vehicle can be
loaded up to the tire’s rated
load.
! Construction type
S13AB010303
Applicable construction of this tire.
For example, “TUBELESS STEEL
BELTED RADIAL”
! Construction
S13AB010304
The generic name of each cord
material used in the plies (both
sidewall and tread area) of this tire.
For example, “PLIES: TREAD 2
STEEL + 2 POLYESTER + 1
NYLON SIDEWALL 2 POLYE-
STER”
! Vehicle placard
S13AB0202
! Uniform Tire Quality Grad-
ing (UTQG)
S13AB010305
For details, refer to “ Uniform tire
quality grading standards” F13-14.
& Recommended tire inflation
pressure
S13AB02
! Recommended cold tire in-
flation pressure
S13AB0201
For the recommended cold tire
inflation pressure for your vehicle’s
tires, refer to “ Tires” F12-9.
The vehicle placard is affixed to the
driver’s side B-pillar.
Example:
