11-28 Maintenance and service/Tires and wheels
WARNING
When a tire’s tread wear indi-
cator becomes visible, the tire
is worn beyond the acceptable
limit and must be replaced
immediately. With a tire in this
condition, driving at high
speeds in wet weather can
cause the vehicle to hydro-
plane. The resulting loss of
vehicle control can lead to an
accident .
NOTE
For safety, inspect the tire tread
regularly and replace the tires
before their tread wear indicators
become visible.
& Rotational direction of tires
& Tire rotation
S11AV11 S11AV07
Example of rotational direction
marked on the sidewall
1) Front Vehicles equipped with 4 non-
unidirectional tires
1) Front
If the tires have specific rotational
direction, refer to the arrow marked
on the side wall.
The arrow should be pointing for-
ward direction when the wheels are
fitted.
