Driving tips/Trailer towing (Outback)
total weight.
. Before towing a trailer, check the
trailer total weight, GVW, GAWs
and tongue load. Make sure the
load and its distribution in your
vehicle and trailer are acceptable.
! Total trailer weight
S08AL0201
8-23
3.6 L models
Conditions
When towing a trailer without brakes.
When towing a trailer with brakes.
When towing a trailer on a long uphill grade
continuously for over 5 miles (8 km) with an
outside temperature of 1048F (408C) or above.
Maximum total trailer weight
1,000 lbs (453 kg)
2,700 lbs (1,224 kg)
1,500 lbs (680 kg)
2.5 L models
Conditions
When towing a trailer without brakes.
When towing a trailer with brakes.
When towing a trailer on a long uphill grade
continuously for over 5 miles (8 km) with an
outside temperature of 1048F (408C) or above.
Maximum total trailer weight
1,000 lbs (453 kg)
2,700 lbs (1,224 kg)
1,350 lbs (612 kg)
Total trailer weight
The total trailer weight (trailer weight plus
its cargo load) must never exceed the
maximum total trailer weight. The max-
imum total trailer weight is indicated in the
following tables.
– CONTINUED –
