Starting and operating/Reverse Automatic Braking System
7-63
NOTE
– When reversing on an uneven road
– The path of the reversing direction is
inclined such as on a steep uphill
– A curb is present in the reversing
direction
– When reversing downhill
. In circumstances such as the following,
it may not be possible to avoid a collision
even when the system operates normally.
– Roads are slippery.
– The tire air pressure is not correct.
– The tires have become worn.
– Tire chains are installed.
– Tires which are not the designated
size are installed.
– Emergency repairs were performed
using a puncture repair kit.
– The suspension was modified.
– Vehicle driving is unstable due to
accident or malfunction.
– The brake warning light is illumi-
nated.
. When the 8-inch audio/navigation
system is performing a software up-
date, the Reverse Automatic Braking
System may not display the following
items on the audio/navigation screen
until the update is complete.
– Display Icon on/off Function
– Distance Indicator Image
– Warning Message
. The Reverse Automatic Braking sys-
tem will operate at vehicle speed be-
tween 1 to 9 mph (1.5 to 15 km/h).
However, stopping the vehicle by auto-
matic hard braking is designed to
operate when the vehicle speed is less
than 3 mph (5 km/h).
& Reverse Automatic Braking
System operation
S07BN03
When Reverse Automatic Braking System
is in operation, an audible warning beeps
will sound in 3 levels to warn the driver of a
potential collision.
While the RAB is operating, a warning
message is displayed on the audio/navi-
gation monitor and the combination meter
display.
– CONTINUED –
