7-55
Starting and operating/BSD/RCTA
away drives on the near side of its lane
from your vehicle
! System temporary stops due to
reduced radar sensitivity
S07BM0802
& BSD/RCTA warning indicator
S07BM04
! System malfunction
S07BM0403
& BSD/RCTA OFF indicator
S07BM08
! System temporary stops
S07BM0801
1)
2)
1)
2)
BSD/RCTA temporary stop message
BSD/RCTA OFF indicator
This display appears when the system is
used at extremely high or low tempera-
tures or when abnormal voltage exists.
Once these conditions are corrected, the
system will recover from the temporary
stop condition and the indicator will dis-
appear.
BSD/RCTA temporary stop message due
to reduced radar sensitivity
BSD/RCTA OFF indicator
This display appears when the detectabil-
ity of the radar sensors is reduced. Once
the condition is corrected, the system will
recover from the temporary stop condition
and the indicator will disappear.
1)
2)
3)
4)
BSD/RCTA malfunction message
At first, this message will appear
Then this message will appear
BSD/RCTA warning indicator
This display appears when a malfunction
occurs in the system. Contact a SUBARU
dealer and have the system inspected.
If the indicator remains displayed for a
prolonged time, have the system in-
spected at a SUBARU dealer.
If the indicator remains displayed for a
prolonged time, have the system in-
spected at a SUBARU dealer.
– CONTINUED –
