Interior equipment/Cargo area cover (Outback – if equipped)
6-17
& To remove the cover housing
CAUTION
S06AK02
1. Rewind the cover.
. Be careful not to scratch the rear
gate stays while extending and
rewinding the cover. Scratches
on the stays could cause leakage
of gas from the stays, which may
result in their inability to hold the
rear gate open.
. When reclining the rear seatback,
move the front cover backward
so that the cover is not damaged.
& To install the front cover
S06AK08
CAUTION
When reclining the rear seatback,
move the front cover backward so
that the cover is not damaged.
1. Align the right side of the front cover
with the triangle mark before fixing the
cover in place.
2. Push the front cover to the right side
and shorten the bar.
3. Align the left side of the front cover with
the triangle mark before fixing the cover in
place.
2. Hold down the button on the right-hand
rear quarter panel and lift up the right-hand
cover housing.
3. Remove the cover housing.
& To remove the front cover
S06AK09
1. Push the front cover to the right side
and shorten the bar.
2. Remove the front cover.
– CONTINUED –
