Interior equipment/Interior light
& Cargo area light (Outback)
S06AA02
Models without SUBARU STARLINK
1) Door interlock switch
The door interlock switch has the following
positions.
OFF: The map lights do not illuminate
automatically in conjunction with a door
opening. But, the lights can be turned on
manually by pressing the map light
switches.
DOOR: The map lights illuminate auto-
matically when any of the doors (other than
the rear gate or trunk lid) is opened even
while the map light switches are in the OFF
position. Several seconds after all of the
doors (other than the rear gate or trunk lid)
are closed, the map lights gradually turn
off. For details, refer to “OFF delay timer”
F6-3.
1)
2)
3)
DOOR
OFF
ON
The cargo area light switch has the
following positions.
DOOR: The light illuminates only when the
rear gate is opened. The light gradually
turns off several seconds after the rear
gate is closed. For derails, refer to “OFF
delay timer” F6-3.
OFF: The light remains off.
ON: The light remains on continuously.
6-3
& OFF delay timer
S06AA07
The following lights have an automatic
illumination function.
. dome light
. map light
. Trunk light (Legacy)
. cargo area light (Outback)
After being illuminated automatically,
these lights remain on for a certain period
of time and then gradually turn off under
the following conditions.
. after the ignition switch is turned to the
“LOCK”/“OFF” position
. after any doors or the rear gate
(Outback) is closed (dome light)
. after all doors are closed (map light)
. after the rear gate is closed (cargo area
light)
. after the doors are unlocked using the
keyless access function (if equipped)
(dome light and map light)
. after the doors are unlocked using the
remote keyless entry system (dome light
and map light)
. when approaching with the access key
fob (if equipped) (dome light and map light)
While the lights are illuminated, if any of
the following operations is performed, the
lights turn off immediately.
– CONTINUED –
