Instruments and controls/Mirrors
& Auto-dimming mirror/com-
pass with HomeLink ® (models
with EyeSight system)
S03AP10
3-77
! To Operate the Auto-Dimming Fea-
ture
S03AP1001
Press the “ ” switch to turn the auto-
dimming feature on/off. The auto-dimming
feature is enabled when the switch’s green
LED indicator is on. The auto-dimming
feature will default to on with each ignition
cycle.
! To Operate the Compass Feature
S03AP1002
1)
2)
3)
HomeLink ® button 1
HomeLink ® button 2
HomeLink ® button 3
1. Press and hold the two outer buttons
(button 1 and button 3) until the indicator
light begins to flash (after approximately
20 seconds).
2. Release both buttons.
! In case a problem occurs
S03AP070408
If you cannot activate a device using
the corresponding HomeLink ® button
after programming, contact HomeLink ®
at www.homelink.com or call 1-800-355-
3515 for assistance.
1)
2)
3)
Display
HomeLink ® buttons
Switch
1. To turn the compass feature on/off,
press and hold the “ ” switch for more
than 3 seconds or until the display turns
on/off. The compass feature will default to
on with each ignition cycle.
2. If the display reads “C”, slowly drive the
vehicle in circles until compass is cali-
brated.
During nighttime driving, the auto-dimming
feature senses distracting glare from
vehicle headlights behind you and auto-
matically dims to eliminate the glare and
help preserve your vision.
Compass calibration zones
– CONTINUED –
