Instruments and controls/Combination meter display
Combination meter display
S03BK
5)
WARNING
6)
Always pay adequate attention to
safe driving when operating the
combination meter display while
the vehicle is in motion. When
operation of the combination meter
display interferes with your ability to
concentrate on driving, stop the
vehicle before performing opera-
tions on the screen. Also, do not
concentrate on the display while
driving. Doing so may cause you to
look away from the road and could
result in an accident.
Various information will be shown on the
combination meter display. Also, a warn-
ing message will appear on the display if a
malfunction, etc. is detected. In addition,
several settings for the displayed content
can be performed.
3-37
to “Select lever/gear position indicator”
F3-30.)
Telltale screen (refer to “Telltale screen”
F3-42.)
Odometer (refer to “Odometer” F3-9.)/
double trip meter (refer to “Double trip
meter” F3-10.)
Control switch
1) Up (select)
2) Set (enter)
3) Down (select)
Combination meter display
1) ECO gauge (refer to “ECO gauge” F3-
12.)
2) Basic screen/Warning screen (refer to
“Basic screens” F3-39 and “Warning
screen” F3-39.)
3) Cruise control information display
4) Select lever/gear position indicator (refer
– CONTINUED –
