Instruments and controls/Warning and indicator lights
: Charge warning light for repair.
: Oil pressure warning light & Seatbelt warning light
and chime
: AT OIL TEMP warning light
/
: ABS warning light
: Vehicle Dynamics Control warning light/
Vehicle Dynamics Control operation
indicator light
: Vehicle Dynamics Control OFF indicator
light
/
: Brake system warning light
: Power steering warning light
: Low tire pressure warning light
(U.S. spec. models)
: Low fuel warning light
: Hill descent control indicator (if
equipped)
If any lights fail to illuminate, it indicates a
burned-out bulb or a malfunction of the
corresponding system.
Consult your authorized SUBARU dealer
Front passenger’s warning light
! Operation
S03AE0101
If the driver and/or front passenger have/
has not yet fastened the seatbelt(s) when
the ignition switch is turned to the “ON”
position, the seatbelt warning light(s) will
flash for 6 seconds, to warn that the
seatbelt(s) is/are unfastened. If the driver’s
seatbelt is not fastened, a chime will also
sound simultaneously.
: All-Wheel Drive warning light
: Automatic headlight beam leveler
warning light (if equipped)
S03AE01
Your vehicle is equipped with a seatbelt
warning device at the driver’s and front
passenger’s seat, as required by current
safety standards.
With the ignition switch turned to the “ON”
position, this device reminds the driver and
front passenger to fasten their seatbelts by
the warning lights in the locations indicated
in the following illustration and a chime.
: Hill Holder indicator light
3-13
NOTE
Driver’s warning light
. If the driver’s and/or front passen-
ger’s seatbelt(s) are/is still not fastened
6 seconds later, the seatbelt warning
device operates as follows according
to the vehicle speed.
– At speeds lower than approxi-
mately 9 mph (15 km/h)
– CONTINUED –
