12-2
Specifications/Specifications
Specifications
S12AA
These specifications are subject to change without notice.
& Dimensions
S12AA01
Item
in (mm)
Legacy
2.5 L
Outback
2.5 L
3.6 L
Drive system
3.6 L
AWD
Transmission type
CVT
Overall length 189.1 (4,802) 189.9 (4,824)
Overall width 72.4 (1,840) 72.4 (1,840)
59.0 (1,500) 66.1 (1,680) *2
65.2 (1,655) *3
64.0 (1,625) *4
Wheelbase 108.3 (2,750) 108.1 (2,745)
Tread Front 62.2 (1,580) 61.8 (1,570)
Rear 62.8 (1,595) 62.2 (1,580)
5.9 (150) 8.7 (220)
Overall height
Ground clearance *1
*1: Measured with vehicle empty
*2: Models with high profile roof rails
*3: Models with low profile roof rails (U.S.-spec. models)
*4: Models with low profile roof rails (except U.S.-spec. models)
CVT: Continuously variable transmission
AWD: All-Wheel Drive
