Maintenance and service/Replacement of wiper blades
grooves in the rubber and slide the blade
rubber assembly into the support until it
locks.
11-33
& Rear window wiper blade as-
sembly (Outback)
S11AZ03
1. Raise the wiper arm off the rear
window.
3. Pull the wiper blade assembly toward
you to remove it from the wiper arm.
1)
2)
Claw
Stopper
4. Be sure to position the claws at the end
of the support between the stoppers on the
rubber as shown. If the rubber is not
retained properly, the wiper blade may
scratch the windshield.
2. Turn the wiper blade assembly coun-
terclockwise.
– CONTINUED –
