1-66
Seat, seatbelt and SRS airbags
SRS airbag system warning light (type B)
A diagnostic system continually monitors
the readiness of the SRS airbag system
(including front seatbelt pretensioners)
while the vehicle is being driven. The
SRS airbag system warning light will show
normal system operation by illuminating
for approximately 6 seconds when the
ignition switch is turned to the “ON”
position.
The following components are monitored
by the indicator.
. Front sub sensor
– Right-hand side
– Left-hand side
. Airbag control module (including impact sensors [all models] and rollover
sensors [Outback])
. Frontal airbag module
– Driver’s side
– Front passenger’s side
. Center pillar impact sensor
– Right-hand side
– Left-hand side
. Front door impact sensor
– Right-hand side
– Left-hand side
. Side airbag module
– Driver’s side
– Front passenger’s side
. Rear wheel house impact sensor
– Right-hand side
– Left-hand side
. Curtain airbag module
– Right-hand side
– Left-hand side
. Seatbelt pretensioner
– Driver’s side
– Front passenger’s side
. Lap belt pretensioner
– Driver’s side
– Front passenger’s side
. Seatbelt buckle switch (front passenger’s side)
. Front passenger’s occupant
