Climate control
tion” mode by pressing the air inlet
selection button.
the instrument panel and some through
windshield defroster outlets (A small
amount of air flows to the windshield and
both side windows to prevent fogging.)
& Temperature control
A)
Models with rear ventilators
(Defrost): Windshield defroster outlets and
both side outlets of the instrument panel
A)
Models with rear ventilators
(Heat-def): Windshield defroster outlets,
foot outlets and both side outlets of the
instrument panel
4-7
NOTE
. When the “ ” mode or “ ” mode
is selected, the air conditioner compressor automatically operates to more
quickly defog the windshield. At the
same time, the air inlet selection is
automatically set to the outside air
mode.
In this state:
– The air conditioner indicator light
does not illuminate.
– You cannot stop the air conditioner compressor by pressing the
air conditioner button.
– You cannot select the “recircula-
! Type A
Turn the temperature control dial over a
range from the blue side (cool) to red side
(warm) to regulate the temperature of
airflow from the air outlets.
! Type B
To increase the temperature setting, press
the “ ” side of the temperature control
button. To decrease the temperature
setting, press the “ ” side of the temperature control button.
Each temperature setting is shown on the
display. When “LO” is shown, the system
provides maximum cooling performance.
When “HI” is shown, the system provides
maximum heating performance.
NOTE
When the “DUAL” button is pressed,
separate temperature settings for the
driver’s side and passenger’s side can
be enabled (DUAL mode). To cancel the
DUAL mode, press the “DUAL” button
again. The temperature setting for the
passenger’s side becomes the same as
the setting for the driver’s side.
– CONTINUED –
