1-32
Seat, seatbelt and SRS airbags
rear seat seatbacks. These marks indicate
the positions of the lower anchorages
(bars).
Each lower anchorage is located behind
the cover of seatback bottom.
selected side of the rear seatback to
expose the anchorages (bars) to be used
for installation of the child restraint system.
CAUTION
The tether anchorages (upper anchorages) are provided for all the seating
positions (center and both window-side
ones) of the rear seat.
When you install a child restraint
system, follow the manufacturer’s
instructions supplied with it. After
installing the child restraint system,
check to ensure that it is held
securely in position. If it is not held
tight and secure, the danger of your
child suffering personal injury in the
event of an accident may be increased.
You will find marks “ ” at the bottom of the
Peel off the anchorage cover from the
Outback
1. While following the instructions supplied by the child restraint system manufacturer, connect the lower hooks onto the
lower anchorages located at “ ” marks on
the bottom of the rear seatback. When the
hooks are connected, make sure the
adjacent seatbelts are not caught.
