Seat, seatbelt and SRS airbags
1-17
Push the button on the buckle.
Before closing the door, make sure that
the belts are retracted properly to avoid
catching the belt webbing in the door.
! Rear center seatbelt on Outback
WARNING
1)
2)
3)
4)
Center seatbelt tongue plate
Connector (tongue)
Connector (buckle)
Center seatbelt buckle
Fastening the seatbelt with the webbing twisted can increase the risk or
severity of injury in an accident.
When fastening the belt after it is
pulled out from the retractor, especially when inserting the connector’s tongue plate into the mating
buckle (on right-hand side), always
check that the webbing is not
twisted.
WARNING
Be sure to fasten both tongue plates
to the respective buckles. If the
seatbelt is used only as a shoulder
belt (with the connector’s tongue
plate not fastened to the connector’s buckle on the right-hand side),
it cannot properly restrain the wearer in position in an accident, possibly resulting in serious injury or
death.
– CONTINUED –
