3-40
Instruments and controls
website at www.homelink.com or
call 1-800-355-3515.
CAUTION
When programming the HomeLink®
Wireless Control System to operate
a garage door opener or an entrance
gate, unplug the device’s motor
from the outlet during programming
to prevent motor burnout.
NOTE
. After programming your HomeLink®
Wireless Control System for the desired devices, retain the hand-held
transmitters for further programming
or device testing in the event of a
problem.
. It is recommended that you insert a
new battery in the hand-held transmitter of a device to ensure correct
programming.
! Garage door opener programming in
the U.S.A.
NOTE
When programming the HomeLink®
Wireless Control System for a garage
door opener, it is suggested that you
park the vehicle outside the garage.
1. Unplug the motor of the garage door
opener from the outlet.
NOTE
If any of the HomeLink® buttons are
already programmed for other devices,
skip step 2 because it clears the
memory of all three buttons.
1)
2)
3)
HomeLink® button 1
HomeLink® button 2
HomeLink® button 3
2. Press and hold the two outer
HomeLink® buttons (button 1 and button
3) until the indicator light begins to flash
(after approximately 20 seconds). Then
release both buttons.
3. Hold the end of the garage door
opener’s hand-held transmitter between
1 and 3 inches (25 and 76 mm) away from
the HomeLink® button you wish to program.
4. Simultaneously press and hold both
the hand-held transmitter button and the
desired HomeLink® button. DO NOT release the buttons until step 5 has been
completed.
