Instruments and controls
indicator needle is pointing to the “+” side,
it indicates fuel-efficient driving.
Warning and indicator lights
Except U.S.-spec. models:
If the current rate of fuel consumption is
lower than the average rate of fuel
consumption, the indicator needle points
to the “−” side. If the current rate of fuel
consumption is higher than the average
rate of fuel consumption, the indicator
needle points to the “+” side. When the
indicator needle is pointing to the “−” side,
it indicates fuel-efficient driving.
Several of the warning and indicator lights
illuminate momentarily and then go out
when the ignition switch is initially turned
to the “ON” position. This permits checking the operation of the bulbs.
Apply the parking brake and turn the
ignition switch to the “ON” position. The
following lights illuminate:
NOTE
. The ECO gauge shows only an
approximate indication.
. After resetting the trip meter, the
average rate of fuel consumption is not
shown until driving 0.6 mile (1 km).
Until that time, the ECO gauge does not
operate.
: Seatbelt warning light
(The seatbelt warning light turns off
only when the driver fastens the
seatbelt.)
: Front passenger’s seatbelt warning
light
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.)
: SRS airbag system warning light
ON /
: Front passenger’s frontal airbag
ON indicator light
/
: Front passenger’s frontal airbag
OFF indicator light
: CHECK ENGINE warning light/Malfunction indicator lamp
: Coolant temperature high warning light
: Charge warning light
3-9
: Oil pressure warning light
: Engine low oil level warning light
: Windshield washer fluid warning light
: AT OIL TEMP warning light
(AT and CVT models)
/
: ABS warning light
: Vehicle Dynamics Control warning
light/Vehicle Dynamics Control operation indicator light
: Vehicle Dynamics Control OFF indicator light
/
: Brake system warning light
: Hill Holder indicator light
: All-Wheel Drive warning light (AT and
CVT models)
: Low tire pressure warning light
(U.S.-spec. models)
: Low fuel warning light
: Door open warning light
: Door open indicator light
: Cruise control indicator light
: Cruise control set indicator light
: Select lever/gear position indicator
– CONTINUED –
