Child Restraint Systems 67 |
||||
! Tether anchorages |
s01ag070102 |
For details , refer to “ Tether Anchorages ” FP70 . |
||
Canada-spec . models |
WARNING
Do not connect two or more lower hooks onto the same anchorage ( bar ).
2 lower anchorages are provided for installing a child restraint system in the rear seat window-side seating positions . Lower anchorages for window-side seating positions may be used for a seat in the center seating position if a child restraint system manufacturer ’ s instructions permit and specify using anchors as far apart as those in this vehicle . Each lower anchorage is located where the seat cushion meets the seatback .
|
1 For the left seat 2 For the center seat 3 For the right seat
The tether anchorages are provided at the locations shown in the above illustration .
|
! To install a child restraint system using lower and tether anchorages s01ag070103
WARNING
Before installing a child restraint system , be sure to confirm that the seatback is securely locked into place . Otherwise , in an accident , serious injury or death could result .
1 . Move the seatback back and forth to confirm that it is securely locked into place . – Check that the red colored unlocking marker on the lock release knob is not visible . For details , refer to “ Folding Down the Rear Seatback ” FP35 .
|
1
Seat , Seatbelt and SRS Airbags
|
|||||
– CONTINUED – |
|||||||||
