Front Seats 31 |
||||||
|
backward. During forward / backward adjustment of the seat, you cannot adjust the seat cushion angle or seat cushion height.
2 Seat cushion angle control switch To adjust the seat cushion angle, pull up or push down the front end of the control switch.
3 Seat height control switch To adjust the seat height, pull up or push down the rear end of the control switch.
4 Seatback angle( reclining) control switch To adjust the angle of the seatback, move the control switch.
5 Lumbar support control switch To increase lower back support, push the front side of the switch. To decrease lower back support, push the rear side of the switch.
|
& Manual Seat( If Equipped) s01aa01
! Forward and backward adjustment s01aa0101
|
1. Sit in the seat to adjust.
2. Pull the lever upward, slide the seat to the desired position, and then release the lever.
3. Try to move the seat back and forth to make sure that it is securely locked into place.
|
! Reclining the seatback
s01aa0102
|
1. Pull up the reclining lever, adjust the seatback to the desired position, and then release the lever.
2. Make sure the seatback is securely locked into place.
The seatback placed in a reclined position can spring back upward with force when pulling up the lever. While operating the lever to return the seatback, hold the seatback lightly so that it may be raised back gradually.
|
1
Seat, Seatbelt and SRS Airbags
|
|
– CONTINUED – |
