! Detecting range |
s07bn0101 |
cancel the system, refer to“ Canceling the Reverse Automatic Braking( RAB) System Operation” FP376. |
. The select lever is in the“ R” position.
. Sonar Audible Alarm OFF indicator is off.
|
|
|
& Operating Conditions s07bn02
The Reverse Automatic Braking( RAB) system will operate when all of the following conditions are met.
|
Sonar Audible Alarm function. Sonar Audible Alarm is set to“ ON”.
. The vehicle speed is from 0 to 9 mph( 0 to 15 km / h).
Automatic Braking function. Automatic Braking is set to“ ON”.
. The vehicle speed is from 1 to 9 mph( 1.5 to 15 km / h).
NOTE
. In the following cases, the Reverse Automatic Braking( RAB) system will not operate. Promptly contact a SUBARU dealer to have the system inspected. – The EyeSight warning indicator is illuminated. – The RAB warning indicator is illuminated.
. In the following cases, the Reverse Automatic Braking( RAB) system cannot be operated. – The( EyeSight Temporary Stop indicator: White) is illuminated, and the messages corresponding to the EyeSight temporary stop are displayed on the combi-
|
|||
|
1 Detecting range( width): Approximately 6 in( 15 cm) outside of the vehicle width
2 Range that the system cannot detect: Approximately 20 in( 50 cm) behind the rear of the vehicle
3 Detecting range( length): Approximately 5 ft( 1.5 m) from the rear of the vehicle
WARNING
If your vehicle is trapped on a railroad crossing and you are trying to escape by reversing through the crossing gate, the system may recognize the crossing gate as an obstacle and brake may activate. In this case, remain calm and either continue to depress the accelerator pedal or cancel the system. To
|
1 EyeSight warning indicator 2 RAB warning indicator 3 RAB OFF indicator 4 Sonar Audible Alarm OFF indicator
. The ignition switch is in the“ ON” position.
. The EyeSight warning indicator is off.. The RAB warning indicator is off.. The RAB OFF indicator is off.
|
7
Starting and Operating
|
||
– CONTINUED – |
||||
