State Emission Testing( U. S. Only) 309
1. Cover the tip of a flat-head screwdriver with vinyl tape or cloth so that it will not scratch. Remove the access cover at the right-side of the cargo area trim using a flat-head screwdriver.
7-2. State Emission Testing( U. S. Only)
WARNING s07ab
3. Pull the clip to unlock the fuel filler lid.
Only use a four-wheel dynamometer when testing an All-Wheel Drive( AWD) model.
Testing of an AWD model must NEVER be performed on a single two-wheel dynamometer. Attempting to do so will result in uncontrolled vehicle movement and may cause an accident or injuries to persons nearby.
7
1 Clip 2. Remove the clip from the trim.
CAUTION
. At state inspection time, remember to tell your inspection or service station in advance not to place your SUBARU AWD vehicle on a two-wheel dynamometer. Otherwise, serious transmission damage will result.
. Resultant vehicle damage due to improper testing is not covered under the SUBARU Limited Warranty and is the responsibility of the state inspection program or
– CONTINUED –
Starting and Operating
