Wireless Charger 291 |
||||
|
! Indicator light patterns
Indicator light
Off
Green( illuminated)
Orange( illuminated)
Green and orange illuminate alternately
s06bh0102
Interpretation The wireless charger is turned off
Standby( ready for charging)* 1
Charging is complete * 2 A mobile device is in the charging area( a mobile device is being detected)
Charging
Quick charging is in progress
* 1: No power is output for charging when the wireless charger is in standby mode. Even if metal objects are placed on the charging tray in this state, they will not overheat.
* 2: For some mobile devices, the indicator light remains orange even after charging is complete.
|
! List of warnings
Indicator light
Flashes orange once per second
Repeatedly flashes orange three times
Possible causes
A communication error occurred between the wireless charger and the access key fob.
Metallic foreign object detected. A foreign object is detected between the mobile device and the charging area. The mobile device is out of alignment: The overheat prevention function of the charging coils was triggered because the mobile device’ s charging coils were out of alignment with the charging area.
Solution
s06bh0103
If the engine is running, stop the engine and restart it. If the ignition switch is in“ ACC”, start the engine once.
Remove any foreign objects between the mobile device and the charging area. Remove the mobile device from the charging area, check that the activation indicator light is illuminating in green again, and place the device in the center of the charging area. If there is a case or cover on your mobile device, be sure to remove it.
|
Indicator light
Repeatedly flashes orange four times
Possible causes
|
The temperature inside the wireless charger has increased.
Solution
Remove the mobile device from the charging area temporarily to stop charging. When the temperature of the heavy electrical equipment cools down, start charging the device again.
NOTE
If you hear noise on the AM radio while your device is charging, you may be able to reduce the noise by changing the charging frequency.
To change the charging frequency, press and hold the power switch to turn on the system.
After a certain amount of time, the indicator light will flash orange twice to indicate the frequency switch.
WARNING
. For safety reasons, drivers must not operate a charging mobile device while driving.
– CONTINUED –
|
6
Interior Equipment
|
