Combination Meter Display( Color LCD) 177 |
|||||||||||||||
|
& Driver Monitoring System Operation Indicator Light( Green)( If Equipped) s03aea4
This indicator illuminates when the Driver Monitoring System is activated. Refer to“ Driver Monitoring System operation indicator light( green)” FP386.
|
& Driver Monitoring System Warning Light( Yellow)( If Equipped) s03aeb6
This warning light illuminates if the Driver Monitoring System malfunctions. We recommend that you have your vehicle inspected at a SUBARU dealer as soon as possible. Refer to“ Driver Monitoring System warning light( yellow)” FP386.
|
& Driver Monitoring System OFF Indicator Light( If Equipped) s03aea5
This indicator illuminates when“ Driver Monitoring System” is touched to deactivate the Driver Monitoring System. Refer to“ Driver Monitoring System OFF indicator light” FP386.
|
& Driver Monitoring System Temporary Stop Indicator Light( If Equipped) s03aea6
This indicator illuminates when the Driver Monitoring System is temporarily stopped. Refer to“ Driver Monitoring System temporary stop indicator light” FP386.
NOTE
The Driver Monitoring System stops temporarily in the following circumstances.
. The temperature of the Driver Monitoring System unit is high.
|
3-7. Combination Meter Display( Color LCD)
WARNING
s03bn
Always pay adequate attention to safe driving when operating the combination meter display( color LCD) while the vehicle is in motion. When operation of the combination meter display( color LCD) interferes with your ability to concentrate on driving, stop the vehicle before performing operations on the screen. Also, do not concentrate on the display while driving. Doing so may cause you to look away from the road and could result in an accident.
Various information will be shown on the combination meter display( color LCD). Also, a warning message will appear on the display if a malfunction is detected. In addition, several settings for the displayed content can be performed.
|
3
Instruments and Controls
|
||||||||||
– CONTINUED – |
