Tires and Wheels 463 |
||||||||
|
4 . Put wheel blocks at the front and rear of the tire diagonally opposite the tire to be replaced .
5 . Take out the jack , jack handle and wheel nut wrench . Refer to “ Maintenance Tools ” FP402 .
NOTE
Make sure that the jack is well lubricated before using it .
|
6 . Loosen the wheel nuts using the wheel nut wrench but do not remove the nuts . |
Turn the jackscrew by hand until the jack head engages firmly into the jack-up point . |
Maintenance and Service |
|||||
11 |
||||||||
|
Jack-up points
7 . Place the jack under the side sill at the front or rear jack-up point closest to the tire to be replaced .
|
8 . Insert the jack handle into the jackscrew , and turn the handle until the tire clears the ground . Do not raise the vehicle higher than necessary . |
|||||||
– CONTINUED – |
