Loading Your Vehicle
& GVWR and GAWR ( Gross Vehicle Weight Rating and Gross Axle Weight Rating )
s08aj02
Certification label
The certification label attached to the driver ’ s side door pillar shows GVWR ( Gross Vehicle Weight Rating ) and GAWR ( Gross Axle Weight Rating ).
The GVW ( Gross Vehicle Weight ) must never exceed the GVWR . GVW is the combined total of weight of the vehicle , fuel , driver , all passengers , luggage , any optional equipment and trailer tongue load . Therefore , the GVW changes depending on the situation .
In addition , the total weight applied to each axle ( GAW ) must never exceed the GAWR . The front and rear GAWs can be adjusted by relocating luggage inside the vehicle .
Even if the total weight of your luggage is lower than the vehicle capacity weight , either front or rear GAW may exceed the GAWR , depending on the distribution of the luggage .
When possible , the load should be evenly distributed throughout the vehicle .
If you carry heavy loads in the vehicle , you should confirm that GVW and front and rear GAWs are within the GVWR and GAWR by putting your vehicle on a vehicle scale , found at a commercial weighing station .
Do not use replacement tires with a lower load range than the originals because they may lower the GVWR and GAWR limitations . Replacement tires with a higher load range than the originals do not increase the GVWR and GAWR limitations .
& Roof Molding and Crossbar s08aj06
CAUTION
. For cargo carrying purposes , the roof molding must be used together with a roof crossbar kit and the appropriate carrying attachment . Otherwise , damage to the roof or paint or a dangerous road hazard due to loss of cargo could result .
. When using the roof crossbar kit , make sure that the total weight of the crossbars , carrying attachment and cargo does not exceed the maximum load limit . Overloading may cause damage to the vehicle and create a safety
