374
Reverse Automatic Braking ( RAB ) System
& Reverse Automatic Braking ( RAB ) System ON / OFF Setting s07bn05
While the select lever is shifted to the “ R ” position , the below functions of the Reverse Automatic Braking ( RAB ) system can be set by operating the center information display .
OFF .
When the OFF setting is shown , the corresponding setting is OFF .
Touch the OFF setting key to turn the setting ON .
When the Automatic Braking function is turned OFF , the following indicator ( s ) will illuminate .
. Warning volume . Sonar Audible Alarm
For details , refer to “ Car settings ” FP199 .
& RAB Warning Indicator s07bn07
1 ON setting key of Automatic Braking function
2 OFF setting key of Automatic Braking function
3 ON setting key of the Sonar Audible Alarm function
4 OFF setting key of the Sonar Audible Alarm function
When the ON setting key is shown , the corresponding setting is ON .
Touch the ON setting key to turn the setting
The RAB OFF indicator will turn off when the corresponding function is turned ON .
NOTE
When the settings cannot be changed , the ON / OFF setting key will be grayed out .
Also , the following settings can be changed by operating the center information display .
1 RAB malfunction message 2 RAB warning indicator
If the Reverse Automatic Braking ( RAB ) system malfunctions , the above indicator illuminates on the combination meter . Contact the nearest SUBARU dealer for details .
