Mirrors 243 |
||||||
|
3-18 . Mirrors
s03ap
Always check that the inside and outside mirrors are properly adjusted before you start driving .
& Inside Mirror ( without Auto- Dimming Function ) ( If Equipped ) s03ap08
1 Normal position 2 Anti-glare position
Push the tab on the mirror for normal use . To reduce glare from the headlights of the vehicle behind you , pull the tab to the antiglare position .
|
& Auto-Dimming Mirror ( If Equipped )
WARNING
s03ap02
To ensure safety , always adjust the mirrors and operate the switch before driving the vehicle . Perform the automatic dimming on / off operation only when necessary . Otherwise , an unexpected accident may occur .
CAUTION
. When cleaning the mirror , use a paper towel or similar material dampened with glass cleaner . Do not spray glass cleaner directly on the mirror because that may cause the liquid cleaner to enter the mirror housing and damage the mirror .
. Sensors detecting brightness are located in front of and behind the mirror . Do not attach any object such as a sticker on the sensor areas or put any object over the mirror .
|
! How to use the auto-dimming mirror s03ap0204 |
1 ON / OFF switch
1 . Move the main body of the autodimming mirror and adjust the position so that you can view the rearward direction sufficiently .
2 . Press the automatic dimming on / off switch to turn the automatic dimming function on or off . The automatic dimming function is enabled when the switch ’ s green LED indicator is on .
NOTE
. Sensors are located in front of and behind the mirror .
. Even with the mirror in the automatic dimming mode , the mirror surface turns bright if the select lever is
|
3
Instruments and Controls
|
||
– CONTINUED – |
