Wiper and Washer 239 |
|||||||||||||||
rubbers ) with new ones . For replacement instructions , refer to “ Replacement of Wiper Blades ” FP467 . |
& Windshield Wiper and Washer Switches s03am01
The wiper operates only when the ignition switch is in the “ ON ” position .
! Windshield wipers
|
: Mist ( for a single wipe )
OFF : Off : Intermittent : Low speed : High speed
s03am0101
|
To turn the wipers off , return the lever to the “ OFF ” position .
For a single wipe of the wipers , push the lever up . The wipers operate until you release the lever .
! Wiper intermittent time control s03am0103
When the wiper switch is in the “ ” position , turn the dial to adjust the operating interval of the wiper . The operating interval can be adjusted in several steps from the shortest interval to the longest .
|
! Windshield washer
s03am0104
|
To wash the windshield , pull the wiper control lever toward you . The washer fluid sprays until you release the lever . The wipers operate while you pull the lever . |
3
Instruments and Controls
|
|||||||||
To turn the wipers on , push the wiper control lever down . |
Windshield washer fluid warning light |
||||||||||||||
– CONTINUED – |
