7-58
Starting and operating / BSD / RCTA
BSD / RCTA OFF indicator ( type B )
If the BSD / RCTA OFF switch is pressed , the BSD / RCTA OFF indicator appears on the combination meter , and the BSD / RCTA is deactivated .
Press the switch again to activate the BSD / RCTA . The BSD / RCTA OFF indicator will disappear .
When this occurs , the BSD / RCTA approach indicator light on the side of the rearview mirror illuminates for a few seconds and then turns off .
NOTE
. In the following cases , the system may not operate properly due to blocked radar waves . Press the BSD / RCTA OFF switch to deactivate the system . – When a bicycle carrier or other item is fitted to the rear of the vehicle – When using a chassis dynamometer or free roller device , etc . – When running the engine and making the wheels rotate while lifting up the vehicle . If the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the last known status of the system is maintained . For example , if the ignition switch is turned to the “ LOCK ”/“ OFF ” position with the BSD / RCTA deactivated , the BSD / RCTA will remain deactivated the next time the ignition switch is turned to the “ ON ” position .
& Certification for the BSD / RCTA
. U . S . -spec. models
FCC ID : OAYSRR3A CAUTION
S07BM06
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user ’ s authority to operate the equipment .
This device complies with part 15 of the FCC Rules . Operation is subject to the following two conditions : ( 1 ) This device may not cause harmful interference , and ( 2 ) this device must accept any interference received , including interference that may cause undesired operation .
