4-8
Climate control / Manual climate control operation
Heat : Foot outlets , both side outlets of the instrument panel and some through windshield defroster outlets ( A small amount of air flows to the windshield and both side windows to prevent fogging .)
Heat-def : Windshield defroster outlets , foot outlets and both side outlets of the instrument panel ( Refer to “ Defrosting ” F4-10 .)
Defrost for type A : Windshield defroster outlets and both side outlets of the instrument panel ( Refer to “ Defrosting ” F4-10 .)
& MAX A / C mode ( for type B and C )
S04AJ06
For quicker cooling , press the MAX A / C button .
When the MAX A / C mode is on , the following settings will be changed automatically .
. The air conditioner will turn on .
. The temperature will be set on the lowest .
. The fan speed will be set on the maximum speed .
. The air inlet will be set to recirculation .
. The air flow mode setting will be set to ventilation mode .
To turn off MAX A / C mode and return the previous setting , press the MAX A / C button again .
& Temperature control
S04AJ02
Turn the temperature control dial to set the preferred interior temperature .
NOTE
The controllable temperature range may vary depending on the regional specifications of the vehicle .
! SYNC mode ( type C )
S04AJ0207
When the SYNC mode is turned on , both the driver ’ s and passenger ’ s side temperatures are synchronized using the driver ’ s side temperature control dial .
Press the SYNC button to turn on the SYNC mode . The SYNC button indicator will illuminate .
Press the SYNC button again or turn the passenger ’ s side temperature control dial to cancel the SYNC mode . The SYNC button indicator will not illuminate . In this case , temperature control on the driver ’ s
