3-34
Instruments and controls / Combination meter display ( color LCD )
& Basic operation
Control switch |
1 ) |
( Up ) |
2 ) |
/ SET ( Enter ) |
3 ) |
( Down ) |
S03BN01
By operating “ ” or “ ” of the control switch , the screens and selection items can be switched . When the “ / SET ” switch is pulled toward you , the item can be selected and set .
If there are some useful messages , such as vehicle information , warning information , etc ., they will interrupt the current screen , and appear on the display accompanied by a beep . If such a screen is displayed , take proper action according to the message shown on the screen .
The warning screen will return to the original screen after a few seconds . While the “ ” information reminder is shown on the display , it may be possible to display the warning screen again . To recall the message marked with “ ” on the display , pull the “ / SET ” switch on the steering wheel toward you .
NOTE
When the multi-function display ( color LCD ) is set to the setting screen , the combination meter display ( color LCD ) cannot be controlled pulling on the “ ”, “ ” and “ / SET ” on the control switch .
& Welcome screen ( opening animation ) and Good-bye screen ( ending animation )
S03BN08
When the driver ’ s door is opened and closed after unlocking the door , the welcome screen ( opening animation ) will appear on the combination meter display ( color LCD ) for approximately 20 seconds .
When the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the combination meter display ( color LCD ) gradually turns off with showing the Good-bye screen ( ending animation ).
NOTE
. The welcome screen and the goodbye screen may differ in the actual words and appearance . . Once the welcome screen appears , it takes a certain period of time to display it again . . If the ignition switch is operated after unlocking the driver ’ s door , the welcome screen will not appear even when the driver ’ s door is opened and closed . . The welcome screen will disappear when you lock the driver ’ s door by using the remote keyless entry system ( all models ) or the keyless access function ( if equipped ) while the welcome screen is displayed . . The welcome screen including the multi-function display ( color LCD ) ( if equipped ) and the audio / navigation unit can be set to on or off . For details , refer to “ Welcome Screen ” F3-38 .
