REAR VIEW CAMERA
No.
Information
Vehicle centerline
Dynamic guidelines
The distance markers show the distance for a level road
when the vehicle is not loaded. It may be different from the
actual distance depending on the loading conditions or road
conditions.
XWhen there is an upward slope at the back
CAUTION
O When moving backward, always check the back with your
eyes without relying on the help lines.
O The actual position and course may be different from the
indication of the help lines.
O Differences may occur due to number of passengers or loaded
cargo.
O When the vehicle is on a slope or when the vehicle is inclined
against the road, the indication is different from the actual
position.
O Be sure to observe the displayed warning message “Check
Surroundings Before Backing Up”.
3 feet (1 m)
Ɣ The distance on the screen looks farther than the
actual distance.
NOTE
O If you set the shift lever/select lever to “R” shortly after turning on
the ignition switch, the warning message “Check Surroundings
Before Backing Up” may not be displayed. Wait for several
seconds or more after turning on the ignition switch before
setting the shift lever/select lever to “R”. Then the warning
message will be displayed.
51
2
Ɣ When the shift lever/select lever is set to position “R”,
the monitor screen displays the help lines together
with the rear view image.
DIFFERENCE BETWEEN SCREEN IMAGE AND
ACTUAL ROAD
