Seat, seatbelt and SRS airbags/Child restraint systems
mode.
(2) Allow the belt to rewind into the
retractor. As the belt is rewinding, clicks
will be heard which indicate the retractor
functions as ALR.
! Installing forward facing child re-
straint
S01AG0402
WARNING
9. To remove the child restraint system,
press the release button on the seatbelt
buckle and allow the belt to retract
completely. The belt will return to the
ELR mode.
7. Push and pull the child restraint system
forward and from side to side to check if it
is firmly secured. Sometimes a child
restraint can be more firmly secured by
pushing it down into the seat cushion and
then tightening the seatbelt.
8. If the seatbelt has been set to the ALR
mode in step 5, pull at the shoulder portion
of the belt to confirm that it cannot be
pulled out (ALR properly functioning).
1-31
NOTE
When the child restraint system is no
longer in use, remove it and restore the
ELR function of the retractor. That
function is restored by allowing the
seatbelt to retract fully.
. NEVER INSTALL A FORWARD OR
REARWARD FACING CHILD
SEAT IN THE FRONT PASSEN-
GER’S SEAT. DOING SO RISKS
SERIOUS INJURY OR DEATH TO
THE CHILD BY PLACING THE
CHILD’S HEAD TOO CLOSE TO
THE SRS AIRBAG.
. Before installing a child restraint
system, be sure to confirm that
the seatback is securely locked
into place. Otherwise, in an acci-
dent, serious injury or death
could result.
1. Shake the seatback slightly to confirm
that it is securely locked into place.
– Check that the red colored unlock-
ing marker which is attached to the
bottom of the lock release knob is
invisible. For details, refer to “Folding
down the rear seatback” F1-6.
2. Prepare the rear seat head restraint
where a child restraint system is intended
to be installed in the following way.
– CONTINUED –
