1-24
Seat, seatbelt and SRS airbags/Seatbelt pretensioners
! In cases of rollover accident, frontal collisions or side collisions, the following components will operate simultaneously
S01AF0201
Driver’s side
seatbelt pre-
tensioner Front passen-
ger’s side
shoulder belt
pretensioner Front passen-
ger’s side lap
belt preten-
sioner SRS frontal
airbag for dri-
ver SRS frontal
airbag for front
passenger SRS curtain
airbags SRS side air-
bags
Rollover accidents * * – – – *
both sides –
Frontal collisions * * * * * *1 *1
Offset frontal
collisions
– –
*
both sides –
* * * * * * *3 * *4 – – – *
impacted side * *2
impacted side
Rear impact – – – – – – –
Minor impact – – – – – – –
Side collisions
*: Activated
–: Not activated
*1: This does not operate if the occupant detection system deactivates airbag operation.
*2: When both the satellite safing sensor and any of the center pillar impact sensors/front door impact sensors sense an impact force.
*3: When both the satellite safing sensor and the driver’s side front door impact sensor sense an impact force.
However, when a center pillar impact sensor detects a signal faster than the front door impact sensor, or both sensors detect signals simultaneously, the
seatbelt pretensioner does not activate.
*4: When both the satellite safing sensor and the front passenger’s side front door impact sensor sense an impact force.
However, when a center pillar impact sensor detects a signal faster than the front door impact sensor, or both sensors detect signals simultaneously, the
seatbelt pretensioner does not activate.
