Seat, seatbelt and SRS airbags/Seatbelt pretensioners
. If the seatbelt retractor assembly or
surrounding area has been damaged,
contact your SUBARU dealer as soon
as possible.
. When you sell your vehicle, we urge
you to inform the buyer that the vehicle
is equipped with seatbelt preten-
sioners. Also, notify the buyer of the
contents of this section.
& Driver’s seatbelt
S01AF08
The driver’s seatbelt has a shoulder belt
pretensioner.
The driver’s seatbelt pretensioner includes
a tension reducing device which limits the
peak forces exerted by the seatbelt on the
occupant in the event of a collision.
When a seatbelt pretensioner is activated,
an operating noise will be heard and a
small amount of smoke will be released.
These occurrences are normal and not
harmful. This smoke does not indicate a
fire in the vehicle.
Once the seatbelt pretensioner has been
activated, the seatbelt retractor remains
locked. Consequently, the seatbelt cannot
be pulled out and retracted and therefore
must be replaced.
Front seatbelt pretensioner
The pretensioner sensor also serves as
follows.
. SRS frontal airbag sensor
. Side impact sensor
. Front door impact sensor
. Rollover sensor
If the sensor detects a certain predeter-
mined amount of force during frontal or
side collisions or rollover accidents, any
seatbelt that has a seatbelt pretensioner is
quickly drawn back in by the retractor to
take up the slack so that the belt more
effectively restrains the seat occupant.
! In cases of rollover accident, frontal
collisions or side collisions, the
following components will operate
simultaneously
S01AF0101
For details, refer to “In cases of rollover
accident, frontal collisions or side colli-
sions, the following components will oper-
ate simultaneously” F1-24.
