1-14
Seat, seatbelt and SRS airbags / Seatbelts
& Emergency Locking Retractor( ELR)
S01AE02
The driver’ s seatbelt has an Emergency Locking Retractor( ELR).
The emergency locking retractor allows normal body movement but the retractor locks automatically during a sudden stop, impact or if you pull the belt very quickly out of the retractor.
& Automatic Locking Retractor / Emergency Locking Retractor( ALR / ELR)
S01AE03
Each passenger’ s seatbelt has an Automatic Locking Retractor / Emergency Locking Retractor( ALR / ELR). The Automatic Locking Retractor / Emergency Locking Retractor normally functions as an Emergency Locking Retractor( ELR). The ALR / ELR has an additional locking mode“ Automatic Locking Retractor( ALR) mode” intended to secure a child restraint system. When the seatbelt is once drawn out completely and is then retracted even slightly, the retractor locks the seatbelt in that position and the seatbelt cannot be extended. As the belt is rewinding, clicks will be heard which indicate the retractor functions as an ALR. When the seatbelt is retracted fully, the ALR mode is released.
When securing a child restraint system on the rear seats by the use of the seatbelt, change the seatbelt to the Automatic Locking Retractor( ALR) mode.
After removing the child restraint system, make sure that the seatbelt retracts fully and the retractor returned to the Emergency Locking Retractor( ELR) mode.
For instructions on how to convert the retractor to the ALR mode and restore it to the ELR mode, refer to“ Installing child restraint systems with ALR / ELR seatbelt” ☞1-29.
& Seatbelt warning light and chime
S01AE04
Refer to“ Seatbelt warning light and chime” ☞3-14.
& Fastening the seatbelt
S01AE06
! Front seatbelts
S01AE0601
1. Adjust the seat position according to the following procedure.
Driver’ s seat: Adjust the seatback to the upright position. Move the seat as far from the steering wheel as practical while still maintaining full vehicle control.
Front passenger’ s seat: Adjust the seatback to the upright position. Move the seat as far back as possible.
2. Sit well back in the seat.
3. Pick up the tongue plate and pull the belt out slowly. Do not let it get twisted.. If the belt stops before reaching the buckle, return the belt slightly and pull it out more slowly.. If the belt still cannot be unlocked, let the belt retract slightly after giving it a strong pull, then pull it out slowly again.
4. Insert the tongue plate into the buckle until you hear a click.
