11-32 Maintenance and service/Replacement of wiper blades
& Window wiper blade rubber
S11AZ05
illustration, so that it can be removed.
2. Pull the end of the wiper blade rubber
through the slit to remove it.
3. To install a new wiper blade rubber,
perform the removal procedure in the
reverse order. After installation, check that
the tip of the wiper rubber has reached the
end of the cap.
& Rear window wiper blade as-
sembly
S11AZ03
1. Raise the wiper arm off the rear
window.
NOTE
It may be difficult to perform the wiper
blade rubber replacement. We recom-
mend that you contact your SUBARU
dealer for wiper blade rubber replace-
ment if necessary.
2. Turn the wiper blade assembly coun-
terclockwise.
Replace the wiper blade rubber according
to the following procedure.
1. Pull the wiper blade rubber until the slit
on the underside of the wiper blade is in
the removal position, as shown in the
