3-62
Instruments and controls/Multi-function display (color LCD)
! Maintenance settings
S03BP2803
You can set maintenance reminders.
! Engine oil setting
S03BP280301
1. Select “Engine Oil” from the 2nd menu
in the setting screen. Refer to “Setting
screen” F3-58.
2. Set the date and distance of the
reminder by using the control switches.
3. Select “Set” to exit settings. Select
“Update” to change the notification dis-
tance to the default value. Select “Go
Back” to return to the previous screen
without applying the setting changes.
NOTE
. The reminder will be displayed by
either date or distance in accordance
with the setting.
. Even when either “Day” or “Dis-
tance” are displayed as “_ _” a pop-up
screen will appear.
. The reminder will be displayed until
either of the following conditions is
satisfied.
– The period of time passed after
the registered notification date is 15
days or more.
– The total distance driven after the
registered notification distance is
approximately 311 miles (500 km) or
more.
! Oil filter setting
S03BP280302
The setting procedure is the same as
“Engine oil setting” F3-62, but select the
“Oil Filter” item in step 1.
! Tires setting
S03BP280303
The setting procedure is the same as
“Engine oil setting” F3-62, but select the
“Tires” item in step 1.
! Maintenance schedule setting
S03BP280304
The setting procedure is the same as
“Engine oil setting” F3-62, but select the
“Maintenance Schedule” item in step 1.
! On/Off setting
S03BP280305
1. Select “On/Off” from the 2nd menu on
the setting screen. Refer to “Setting
screen” F3-58.
2. Select “On” or “Off” to turn the opening
screen on or off by using the control
switches.
3. Select “Set” to exit settings. Select “Go
Back” to return to the previous screen
without applying the setting changes.
! Clear setting
S03BP280306
1. Select “Clear All Settings” from the 2nd
menu on the setting screen. Refer to
“Setting screen” F3-58.
