3-42
Instruments and controls/Combination meter display (color LCD)
By operating the “ ” or “ ” switch on the
steering wheel, you can select the menu.
Pull the “ /SET” switch to enter the
selected menu.
NOTE
If you enter the “Go Back” menu, the
system will return to the previous
screen.
! Screen Settings
S03BN0701
After entering the “Screen Settings” menu,
select one of the following menus.
! Welcome Screen
S03BN070101
The combination meter display (color
LCD), multi-function display (color LCD),
and audio/navigation unit of welcome
screen can be activated or deactivated.
! Good-bye Screen
S03BN070106
The good-bye screen can be activated or
deactivated.
! Gauge Initial Movement
S03BN070102
The movement of the meter needles and
gauge needles that occurs when the
ignition switch is turned to the “ON”
position can be activated or deactivated.
! Units
S03BN070108
Changes the units displayed in the combi-
nation meter display (color LCD), the type
A multi-function display (black and white)
and the type B multi-function display (color
LCD).
! Tire Pressure Units (if equipped)
S03BN070109
Changes the units displayed in the Tire
Pressure Monitoring system.
! Languages
S03BN070103
Changes the language displayed in the
combination meter display (color LCD)
and the multi-function display (color LCD).
! Warning Volume (if equipped)
S03BN0713
Sets the EyeSight warning volume, the
BSD/RCTA warning volume and the RAB
warning volume.
! EyeSight (models with the EyeSight
system)
NOTE
S03BN0702
Refer to the Owner’s Manual supple-
ment for the EyeSight system.
! RAB (models with the EyeSight
system)
S03BN0712
The Sonar Audible Alarm can be set to on
or off.
NOTE
For details about the Reverse Auto-
matic Braking system, refer to “Re-
verse Automatic Braking System” F7-
58.
! Sonar Audible Alarm
S03BN071204
When the Reverse Automatic Braking
system is in operation, the warning sound
to notify that an obstacle is detected in the
rear can be activated or deactivated.
! Vehicle Setting
S03BN0708
After entering the “Vehicle Setting” menu,
select one of the following menus.
! Keyless Entry System
S03BN070801
Sets the settings used when the keyless
access function was operated.
. Audible Signal (if equipped)
Sets the electronic chirp that sounds when
the door is locked or unlocked.
. Hazard Warning Flasher
Sets the operation of the hazard warning
f lasher that blinks when the door is locked
or unlocked.
