3-54
Instruments and controls/Multi–function display (color LCD)
! Electric components operation
screen
1)
Lane Departure/Sway Warning indica-
tor* 1
2) Pre-Collision Braking System indicator* 1
3) Stop lights
4) Reverse Automatic Braking (RAB)* 1
5) BSD/RCTA* 1
6) Headlights* 2
7) Front fog lights* 2
8) Turn signals
9) Auto on/off headlights* 1
*1: If equipped
*2: The daytime running lights are not
displayed.
This screen displays the electric compo-
nents operation status of the vehicle.
NOTE
. Indicators do not display for func-
tions that are not equipped to the
vehicle.
. The indicators of functions that are
not operating are displayed in grey.
. For models with auto on/off head-
lights; If the multi-function display
(color LCD) unit, battery, or fuse is
removed, the Auto on/off headlights
indicator turns off on the multi-function
display (color LCD). After reinstalling
the removed multi-function display
(color LCD) unit, battery, or fuse to the
vehicle, the Auto on/off headlights
indicator will appear once more if the
light control switch is turned to the
“AUTO” position.
! Prevention safety screen
1)
2)
3)
4)
Telltale screen
Steering angle
Vehicle posture
Running condition
This screen displays the driving status of
the vehicle and the operation status
functions. For functions that are operating,
the indicator will illuminate or flash.
NOTE
The vehicle posture indication may
differ from the actual vehicle posture.
