3-34
Instruments and controls/Combination meter display (color LCD)
5)
Combination meter display
(color LCD) (if equipped)
6)
7)
WARNING
Always pay adequate attention to
safe driving when operating the
combination meter display (color
LCD) while the vehicle is in motion.
When operation of the combination
meter display (color LCD) interferes
with your ability to concentrate on
driving, stop the vehicle before
performing operations on the
screen. Also, do not concentrate
on the display while driving. Doing
so may cause you to look away from
the road and could result in an
accident.
Various information will be shown on the
combination meter display (color LCD).
Also, a warning message will appear on
the display if a malfunction, etc. is
detected. In addition, several settings for
the displayed content can be performed.
8)
A:
B:
Combination meter display (color LCD)
1) ECO gauge
2) Warning screen (refer to “Warning
screen” F3-36.)/Basic screen (refer to
“Basic screens” F3-37.)
3) EyeSight screen
4) Cruise control information display
Telltale screen (refer to “Telltale screen”
F3-36.)
Select lever/gear position indicator (refer
to “Select lever/gear position indicator
(CVT models)” F3-31.)
Odometer (refer to “Odometer” F3-9.)/
double trip meter (refer to “Double trip
meter” F3-9.)
Fuel gauge (refer to “Fuel gauge” F3-
10.)
Deactivating the Eyesight system or
models without the Eyesight system
Activating the Eyesight system
